IRC Code 118-2015): Guidelines for the Design and Construction of Continuously Reinforced Concrete Pavement

‍

The IRC:118-2015 provides comprehensive guidelines for designing and constructing Continuously Reinforced Concrete Pavement (CRCP). Published by the Indian Roads Congress, this document addresses the specific needs of high-traffic roads, emphasizing durability, reduced maintenance, and improved performance. Below, we explore the key aspects of the code and its applications in detail.

‍

‍

What is Continuously Reinforced Concrete Pavement (CRCP)?

‍

CRCP is a type of rigid pavement designed to eliminate the need for transverse joints by incorporating continuous steel reinforcement. Unlike jointed concrete pavements, CRCP is constructed to manage natural cracking due to shrinkage, temperature, and other stresses. It is especially suited for highways, expressways, and roads with high commercial traffic where frequent maintenance closures are not feasible.

‍

Advantages of CRCP

‍

1. Durability: CRCP is rugged and durable, making it ideal for high-traffic roads and heavy-load corridors.
2. Minimal Maintenance: Since there are no transverse joints, issues like joint maintenance and seal replacement are eliminated, reducing costs over time.
3. Longer Lifespan: CRCP typically lasts 30–40 years, offering a lower lifecycle cost despite higher initial investments.
4. Reduced Water Infiltration: Narrow cracks and the absence of numerous joints minimize water seepage, protecting the subgrade.
5. Improved Ride Quality: The absence of joints provides a smoother riding surface with fewer interruptions.

‍

Disadvantages of CRCP

‍

1. High Initial Cost: The construction involves a significant investment due to the use of continuous steel reinforcement.
2. Corrosion Risks: In marine climates, steel reinforcement is vulnerable to corrosion, requiring the use of epoxy-coated or galvanized steel.
3. Utility Constraints: CRCP is not ideal for roads with frequent utility lines beneath, as cutting and dismantling the pavement can be challenging.
4. Construction Complexity: Manual construction is discouraged due to inefficiency and higher costs. Slipform pavers and other advanced machinery are essential.

‍

Typical Pavement Composition

‍

A CRCP consists of several layers:

1. Base and Subbase Layers: These can be made of dry lean concrete (DLC) or bituminous bases. A geosynthetic layer is sometimes added for better performance.
2. Reinforced Concrete Layer: This is the main pavement layer, typically 250–300 mm thick, designed based on traffic volume and environmental conditions.

‍

Design of CRCP

‍

Thickness Design

• The thickness is determined using guidelines from IRC:58-2011 for plain jointed rigid pavements.
• No reduction in thickness is recommended for CRCP, as thinner pavements have shown poor performance in the past.

Reinforcement Design

• Longitudinal Reinforcement: Typically accounts for 0.65% to 0.8% of the cross-sectional area of the pavement. It controls transverse cracks, ensuring they remain narrow and evenly spaced.
• Transverse Reinforcement: Helps prevent longitudinal cracks and punchouts. The spacing is calculated to balance the forces caused by concrete contraction and friction.

Shoulders

• Full-depth concrete shoulders are recommended for better edge support and to minimize punchouts.
• Tied longitudinal joints connect the shoulders to the main pavement for stability.

‍

Construction of CRCP

‍

1. Reinforcement Placement: Steel bars are installed using robust chair assemblies to ensure proper positioning and support during concrete pouring.
2. Paving Operations: Slipform pavers are commonly used for efficient construction. Conveyor belt systems or side-tipping methods are used to pour concrete without disturbing the reinforcement.
3. Construction Joints: Transverse construction joints are made at the end of each day’s work, with additional reinforcement to maintain structural integrity.

‍

Common Issues in CRCP

‍

1. Punchouts: These occur near pavement edges when cracks are too close, leading to structural failures under heavy loads.
2. Corrosion: In marine environments, unprotected steel reinforcement can corrode, compromising the pavement's durability.
3. Crack Management: Ensuring narrow and evenly spaced cracks is essential to prevent spalling and water penetration.

‍

Applications of CRCP

‍

CRCP is best suited for:

• Highways and expressways
• Roads with heavy commercial traffic
• Areas with challenging soil conditions requiring durable solutions

However, it is not recommended for village roads, urban streets with light traffic, or areas with frequent utility lines.

‍

Conclusion

‍

The IRC:118-2015 serves as a definitive guide for designing and constructing CRCP, ensuring long-lasting and low-maintenance roads. By eliminating transverse joints and incorporating continuous steel reinforcement, CRCP offers a durable solution for high-traffic corridors. Although the initial cost is higher, the lower maintenance requirements and extended lifespan make it a cost-effective choice for critical road infrastructure. Adopting these guidelines can significantly improve road performance, ensuring safety and efficiency for decades to come.

‍
