Understanding the IRC Code: IRC 107-2013 - Specification for Bitumen Mastic Wearing Courses

‍

The Indian Roads Congress (IRC) has established a comprehensive set of guidelines under IRC Code 107-2013, focusing on the specifications for bitumen mastic wearing courses. This document serves as a crucial resource for civil engineers, contractors, and road construction professionals, providing essential insights into the design, construction, and quality control of bitumen mastic wearing courses.

‍

‍

Introduction to IRC Code 107-2013

‍

Originally published in 1992, the specifications for bitumen mastic wearing courses have undergone significant revisions to incorporate advancements in technology and construction practices. The Flexible Pavement Committee recognized the need for an updated document, leading to the formation of a sub-group tasked with revising the original guidelines. The revised document was approved by various committees and the IRC Council, ensuring it reflects the latest industry standards.

‍

Scope of the Specification

‍

IRC Code 107-2013 outlines the fundamental requirements for the design, construction, and control of bitumen mastic wearing courses. This specification is not intended for thin mastic layers on bridge decks beneath a bituminous concrete layer. The bitumen mastic is composed of graded mineral filler, coarse aggregates, fine aggregates, and a hard grade of bitumen, forming a coherent, voidless, and impermeable mass. This material is designed to be solid or semi-solid at normal temperatures but fluid enough to be spread during application.

‍

Material Requirements

‍

1. Bitumen: The primary binder used in mastic asphalt is industrial-grade 85/25 bitumen, which must meet specific physical properties, including penetration, softening point, ductility, and solubility. For high-altitude areas, VG 40 grade binder is recommended.
2. Coarse Aggregate: The coarse aggregates must be clean, hard, and durable, free from disintegrated pieces and organic matter. They should meet specific physical requirements, including impact value, flakiness index, and soundness.
3. Fine Aggregates: Fine aggregates can be crushed hard rock or natural sand, passing through a 2.36 mm sieve. The grading of fine aggregates, including filler material, is specified in the guidelines.
4. Filler: The filler material must be limestone powder with a calcium carbonate content of at least 80% by weight.

‍

Mix Design and Composition

‍

The mix design for bitumen mastic involves determining the hardness number and binder content. The hardness number must conform to specified limits, both with and without coarse aggregates. The binder content is adjusted to achieve the desired mix properties, ensuring optimal performance.

‍

Construction Operations

‍

The construction of bitumen mastic involves several critical stages:

1. Manufacture: The filler is heated and mixed with bitumen, followed by the addition of fine aggregates and coarse aggregates. The entire process requires careful temperature control to avoid overheating.
2. Laying the Mix: The base must be prepared and cleaned before laying the mastic. The bitumen mastic is then spread uniformly on the prepared surface, ensuring proper thickness and temperature.
3. Transportation: For long-distance transport, the mastic must be kept heated and agitated to maintain consistency. For shorter distances, it can be transported in wheelbarrows or flat pans.
4. Surface Finish: The finished surface must be tested for irregularities, ensuring no depressions greater than 4 mm are present.

‍

Quality Control Measures

‍

Quality control is paramount in the construction of bitumen mastic wearing courses. Regular testing of materials, including sieve analysis, physical properties of aggregates, and bitumen characteristics, is essential. The temperature of the mastic during laying must be monitored, and any irregularities in the surface must be corrected promptly.

‍

Conclusion

‍

IRC Code 107-2013 provides essential guidelines for the effective use of bitumen mastic wearing courses in road construction. By adhering to these specifications, civil engineers and contractors can ensure the durability, safety, and performance of road surfaces, ultimately contributing to improved infrastructure and road safety.

‍
