IRC Code 35: Ensuring Safety at Intersections with Transverse Road Markings

‍

Intersection safety is a vital aspect of road design and traffic management. Among the key elements that enhance this safety are transverse road markings, a critical subset of road markings defined and standardized under IRC Code 35-2015 by the Indian Roads Congress. These markings guide, control, and warn road users, helping reduce conflicts and promote orderly traffic movement at junctions and crossings.

‍

In this blog, we explore transverse road markings as per IRC Code 35, their types, applications, design principles, and role in enhancing road safety—especially at intersections.

‍

‍

‍

What Are Transverse Road Markings?

‍

Transverse road markings are lines painted across the direction of vehicle travel, primarily intended to control traffic at intersections, junctions, and crossings. According to IRC:35-2015, they include:

‍

• Stop Lines
• Give Way (Yield) Lines
• Pedestrian Crossings
• Thermoplastic Bars for Speed Calming

‍

These markings are vital for imposing control measures such as “Stop” or “Yield” and for guiding vulnerable road users like pedestrians and cyclists.

‍

Importance of Transverse Markings at Intersections

‍

Transverse markings serve as visual signals to inform drivers of critical decision points ahead. At intersections—where the risk of accidents is highest—they:

‍

• Indicate mandatory stopping or yielding

• Enhance pedestrian safety

• Clarify vehicle priority

• Warn of merging or diverging traffic

• Support the effectiveness of road signs

‍

They function in synergy with vertical signs and traffic signals to ensure smooth and safe vehicular and pedestrian movement.

‍

Types of Transverse Markings Under IRC Code 35

‍

1. Stop Lines (TM01)

‍

As per Section 6.1 of IRC:35-2015:

‍

• A solid white line across the carriageway.

• Installed at signalized intersections, stop-controlled junctions, and pedestrian crossings.

• Must be placed at least 1.5 m ahead of the nearest edge of the crosswalk or intersection to ensure visibility and reaction time.

• Should be 150 mm thick for better visibility, especially in urban areas.

‍

2. Give Way Lines (TM02, TM03)

‍

According to Section 6.2:

‍

• Made of broken lines, typically with 450 mm long segments and 150 mm gaps.

• Positioned at unsignalized intersections to caution drivers to yield to major road traffic.

• Often used in conjunction with triangular Give Way signs painted on the carriageway.

‍

3. Pedestrian Crossings (BM01)

‍

Covered under Section 11.3:

‍

• Marked as zebra patterns using white rectangular blocks.

• Recommended width: 2.5 m to 4 m, depending on traffic volume.

• Installed at mid-block locations, intersections, schools, and bus stops.

‍

4. Thermoplastic Bar Markings

‍

Per Section 11.2:

‍

• Used as speed calming devices on approaches to intersections.

• Installed as parallel transverse bars, typically 150 mm wide, spaced at 500 mm intervals.

• They generate auditory and vibrational feedback to alert drivers.

‍

Material Specifications

‍

IRC Code 35 recommends the use of durable and high-visibility materials for transverse markings, such as:

‍

• Thermoplastic paint (hot-applied)

• Cold-applied plastics

• Preformed adhesive tapes (for high-traffic urban areas)

• Use of glass beads is encouraged to enhance retro-reflectivity, especially during night or wet weather conditions.

‍

Design and Placement Guidelines

‍

The code emphasizes precise placement based on intersection geometry:

‍

• Stop lines should be placed to ensure a clear view of cross-traffic.

• Give Way lines must be supplemented by advance warning signs.

• For complex junctions (e.g., ghost islands or staggered intersections), transverse markings should be tailored to guide lane discipline.

• In roundabouts, transverse lines are used to define yield points at entries.

‍

Maintenance and Performance Monitoring

‍

Section 15 and 16 of IRC:35-2015 underline:

‍

• Periodic retro-reflectivity testing

• Monitoring durability and skid resistance

• Ensuring uniformity across the network

• Repainting or replacement as per wear-and-tear metrics

‍

Well-maintained transverse markings contribute significantly to accident reduction and traffic flow efficiency.

‍

Common Locations Where Transverse Markings Are Essential

‍

• Urban signalized intersections

• Rural T-junctions and staggered crossings

• Pedestrian-dense areas like schools or markets

• Merging zones in roundabouts

• Speed-sensitive zones before crossings

‍

Integration with Road Studs and Signs

‍

For enhanced guidance:

‍

• Red or white retro-reflective studs are used with stop lines

• Raised pavement markers increase nighttime visibility

• Must be synchronized with vertical signs for consistent messaging

‍

Conclusion

‍

Transverse road markings, though often overlooked, are fundamental to intersection safety. Adhering to the IRC Code 35-2015 ensures their design, placement, and maintenance are uniform, effective, and responsive to Indian road conditions. As urbanization accelerates and traffic grows denser, well-implemented transverse markings can save lives by making our intersections more predictable, safer, and efficient.

‍
