Unveiling IRC Code 119:2015 – Comprehensive Guidelines for Traffic Safety Barriers

‍

The IRC Code 119:2015, published by the Indian Roads Congress, is an essential resource for enhancing road safety. It offers detailed guidelines for designing, installing, and maintaining traffic safety barriers, also known as crash barriers. These barriers play a crucial role in preventing accidents on high-speed highways, particularly in hazardous locations such as sharp curves, bridge approaches, and high embankments. This blog explores the core aspects of IRC Code 119:2015, focusing on its types, requirements, and practical applications.

‍

‍

Understanding Traffic Safety Barriers

‍

Traffic safety barriers are engineered systems designed to prevent vehicles from leaving the roadway or colliding with fixed objects. Their primary functions include:

1. Redirecting vehicles parallel to the barrier direction during impacts.
2. Minimizing accident severity and property damage.
3. Enhancing safety for road users, including pedestrians and cyclists.

‍

Types of Traffic Safety Barriers

‍

IRC Code 119:2015 categorizes traffic safety barriers into two main types:

1. Road Edge Barriers

• Installed along the edges of roads to shield vehicles from embankments, ditches, and fixed roadside obstacles.
• Common applications: High embankments, bridge rail ends, and accident-prone black spots.

2. Median Barriers

• Positioned in the median of divided highways to prevent head-on collisions.
• Common applications: Narrow medians, high-traffic roads, and areas with frequent median crossovers.

‍

Barrier Types Based on Performance

‍

Traffic safety barriers are further classified by their deflection characteristics:

1. Flexible Barriers: Cable or wire rope systems that deflect significantly upon impact, reducing the force transmitted to vehicles.
2. Semi-Rigid Barriers: Steel beam barriers offering moderate deflection while effectively redirecting vehicles.
3. Rigid Barriers: Concrete barriers with minimal deflection, suited for areas with restricted space.

‍

Key Requirements of Traffic Safety Barriers

‍

IRC Code 119:2015 outlines essential criteria for safety barriers to ensure their effectiveness:

1. Adequate space behind the barrier to permit deflection.
2. Prevention of vehicle penetration or overturning during impact.
3. Minimal intrusion into adjacent traffic lanes post-impact.
4. Robust visual guidance for drivers.
5. Cost-effective installation and maintenance.
6. Crash-tested designs for proven field performance.

‍

Practical Applications of Safety Barriers

‍

Road Edge Barriers

• Used in locations with steep slopes, bridge approaches, or roadside hazards.
• Examples: W-beam barriers, thrie beam barriers, and wire rope barriers.

Median Barriers

• Essential for narrow medians or high-traffic highways to prevent crossovers.
• Examples: Concrete barriers, dual-sided W-beam barriers, and wire rope systems.

‍

Advantages of Implementing IRC Code 119:2015

‍

1. Enhanced Road Safety: Reduces accident severity and protects vulnerable road users.
2. Operational Efficiency: Minimizes traffic disruptions during accidents.
3. Cost-Effectiveness: Ensures durability with reduced maintenance costs.
4. Field-Tested Designs: Incorporates proven international practices for reliability.

‍

Conclusion

‍

The IRC Code 119:2015 serves as a vital guide for engineers and road safety professionals, ensuring the effective design and deployment of traffic safety barriers. By adhering to these guidelines, road authorities can significantly enhance highway safety, reduce accidents, and save lives.

‍
